J305 conversion factor
1 week 4 days ago #7170
by FSM19
J305 conversion factor was created by FSM19
Does anyone have a conversion factor for the Chinese J305 tube? I've just realised when I changed over counters, I put in one rather than the SBM20 I had been using.
Please Log in or Create an account to join the conversation.
1 week 4 days ago #7171
by Simomax
Replied by Simomax on topic J305 conversion factor
It is either 0.00332 or 0.00812. I have no idea which, or even if they are correct. I have been using 0.00812 for the J305, but I'm unsure if this is correct. I have never found a solid answer to this, nor have I ever found an actual proper data sheet for this tube, only a couple of tables on aliexpress/amazon/ebay that state their sensitivity, and I have found differing numbers for the same tube. I also think there has been more than one iteration of the J305 as some measure 88mm and some measure more. I also have a J305 that is sensitive to light, and one that isn't, and I have one that looks like a copy of the J305 with no markings on the tube. It is these discrepancies that puts me off using the J305.
There is some discussion about the conversion factor on Steadramon's ESPGeiger github page here: https://github.com/steadramon/ESPGeiger/discussions/14
If I had a more solid answer, I' d be happy to help, but I've been struggling with this myself.
There is some discussion about the conversion factor on Steadramon's ESPGeiger github page here: https://github.com/steadramon/ESPGeiger/discussions/14
If I had a more solid answer, I' d be happy to help, but I've been struggling with this myself.
The following user(s) said Thank You: FSM19
Please Log in or Create an account to join the conversation.
1 week 1 day ago #7172
by Simomax
Replied by Simomax on topic J305 conversion factor
I asked ChatGPT if it could find the conversion factor. It says the recommended number is 0.00332 for background monitoring. The conversation is in the PDF attached.
Attachments:
The following user(s) said Thank You: iotdevicesdev
Please Log in or Create an account to join the conversation.
- iotdevicesdev
-
- Offline
- New Member
-
Less
More
- Posts: 1
- Thank you received: 2
5 days 13 hours ago #7175
by iotdevicesdev
Replied by iotdevicesdev on topic J305 conversion factor
It seems that AI quotes our publications. You can read them here:
Geiger tube J305: How to calculate the conversion factor of CPM to μSv/h. Technical note:
https://iot-devices.com.ua/en/geiger-tube-j305-how-to-calculate-the-conversion-factor-of-cpm-technical-note-en/
Geiger tube J305 conversion factor: differences between the coefficient for source radiation power and absorbed dose. Technical note:
https://iot-devices.com.ua/en/geiger-tube-j305-conversion-factor-difference-for-radiation-source-power-and-absorbed-dose-technical-note-en/
Best Regards,
Oleksii
IoT-devices, LLC
Geiger tube J305: How to calculate the conversion factor of CPM to μSv/h. Technical note:
https://iot-devices.com.ua/en/geiger-tube-j305-how-to-calculate-the-conversion-factor-of-cpm-technical-note-en/
Geiger tube J305 conversion factor: differences between the coefficient for source radiation power and absorbed dose. Technical note:
https://iot-devices.com.ua/en/geiger-tube-j305-conversion-factor-difference-for-radiation-source-power-and-absorbed-dose-technical-note-en/
Best Regards,
Oleksii
IoT-devices, LLC
